Product Information
Adopt curved surface technology aesthetic design, smile curve front face, automatic cat-eye headlights, 15-inch aluminum alloy wheels, quantum fluid LED taillight, etc. Before using smooth line draw the outline of body, closed-end China also adopt the oval design, at the same time, fast charge/slow filling charging interface hidden inside the former LOGO, blackened type headlamps USES circular design, internal two circular chrome trim have very good adornment effect, and hidden semicircle LED daytime running lights hidden in the lateral chrome trim. The side lines of the car body are simple, and the short front and rear suspension design can provide plenty of space inside the car.
With 403KM long endurance. Ningde Era high-performance battery PACK is adopted, which enables the battery system to have a high energy density of 171Wh/kg. In the aspect of three-power safety, the high and low voltage isolation design is adopted, and the live body is fully isolated and insulated. Through vibration, impact, extrusion, fire, sea water immersion and other safety tests, the IP67 safety protection grade is reached. In addition, Leap Motor T03 is equipped with intelligent liquid constant temperature management system, which can heat and cool the battery, effectively control the battery charging and working temperature, and improve battery safety.
Equipped with 42-inch panoramic muting glass canopy (with electric shading curtain), integrated leather seats, ergonomic door handles, decorative panels with the same color as exterior decorations, 15 storage Spaces, all make the interior space of the vehicle transparent, spacious and comfortable.
The system is equipped with 8-inch intelligent suspended LIQUID crystal instrument and 10.1-inch high-definition touch screen. The steering wheel is a three-frame flat-bottom multi-function steering wheel. Inside the a-pillar of the main driver's seat, the new car is also equipped with A face recognition activation system, which is rare in its class. The seats in the new car are wrapped in leather and the rear seats can be reclined as a whole.
Product Specifications
| Brand | Leap Motor |
| Model | T03 |
| Version | 2022 Star Diamond Edition |
| Basic parameters | |
| Car model | Minicar |
| Type of Energy | Pure electric |
| Time to market | Dec,2021 |
| NEDC pure electric cruising range (KM) | 403 |
| Fast charging time[h] | 0.6 |
| Fast charge capacity [%] | 80 |
| Slow charging time[h] | 3.5 |
| Maximum power (KW) | 80 |
| Maximum torque [Nm] | 158 |
| Motor horsepower [Ps] | 109 |
| Length*width*height (mm) | 3620*1652*1592 |
| Body structure | 5-door 4-seat hatchback |
| Top Speed (KM/H) | 100 |
| Official 0-100km/h acceleration (s) | 12 |
| Car body | |
| Longth(mm) | 3620 |
| Width(mm) | 1652 |
| Higth(mm) | 1592 |
| Wheel base(mm) | 2400 |
| Front track (mm) | 1410 |
| Rear track (mm) | 1410 |
| Minimum ground clearance (mm) | 140 |
| Body structure | hatchback |
| Number of doors | 5 |
| Number of seats | 4 |
| Trunk volume (L) | 210-508 |
| Electric motor | |
| Motor type | Permanent magnet synchronization |
| Total motor power (kw) | 80 |
| Total motor torque [Nm] | 158 |
| Front motor maximum power (kW) | 80 |
| Front motor maximum torque (Nm) | 158 |
| Number of drive motors | Single motor |
| Motor placement | Prepended |
| Battery Type | Lithium iron phosphate battery |
| NEDC pure electric cruising range (KM) | 403 |
| Battery Power(kwh) | 41 |
| Gearbox | |
| Number of gears | 1 |
| Transmission type | Fixed gear ratio gearbox |
| Short name | Electric vehicle single speed gearbox |
| Chassis Steer | |
| Form of drive | Rear-engine Rear-drive FF |
| Type of front suspension | McPherson independent suspension |
| Type of rear suspension | Torsion Beam Dependent Suspension |
| Boost type | Electric assist |
| Car body structure | Load bearing |
| Wheel braking | |
| Type of front brake | Ventilated Disc |
| Type of rear brake | Disc |
| Type of parking brake | Electronic brake |
| Front Tire Specifications | 165/65 R15 |
| Rear tire specifications | 165/65 R15 |
| Cab Safety Information | |
| Primary driver airbag | YES |
| Co-pilot airbag | YES |
| Tire pressure monitoring function | Tire pressure display |
| Seat belt not fastened reminder | First row |
| ISOFIX Child seat connector | YES |
| ABS anti-lock | YES |
| Brake force distribution (EBD/CBC, etc.) | YES |
| Brake Assist (EBA/BAS/BA, etc.) | YES |
| Traction Control (ASR/TCS/TRC, etc.) | YES |
| Body Stability Control (ESC/ESP/DSC, etc.) | YES |
| Lane Departure Warning System | YES |
| Lane Keeping Assist | YES |
| Road traffic sign recognition | YES |
| Active Braking/Active Safety System | YES |
| Fatigue driving tips | YES |
| Assist/Control configuration | |
| Front parking radar | YES |
| Rear parking radar | YES |
| Driving assistance video | Reverse image |
| Cruise system | Full speed adaptive cruise |
| Driving mode switching | Sport Economy Standard Comfort |
| Automatic parking | YES |
| Automatic parking | YES |
| Hill assist | YES |
| External / Anti-Theft Configuration | |
| Sunroof type | Panoramic sunroof cannot be opened |
| Rim material | Aluminum alloy |
| Interior central lock | YES |
| Key type | Remote key |
| Keyless start system | YES |
| Remote start function | YES |
| Battery preheating | YES |
| Internal configuration | |
| Steering wheel material | Cortex |
| Steering wheel position adjustment | Manual up and down |
| Multifunction steering wheel | YES |
| Trip computer display screen | Color |
| Full LCD Dashboard | YES |
| LCD meter size (inch) | 8 |
| Built-in driving recorder | YES |
| Seat configuration | |
| Seat materials | Limitation leather |
| Driver's seat adjustment | Front and rear adjustment, backrest adjustment, height adjustment (2-way) |
| Co-pilot seat adjustment | Front and rear adjustment, backrest adjustment |
| Rear seats folded down | Whole down |
| Multimedia configuration | |
| Central control color screen | Touch LCD |
| Central control screen size (inch) | 10.1 |
| Satellite navigation system | YES |
| Navigation traffic information display | YES |
| Bluetooth/Car Phone | YES |
| Voice recognition control system | Multimedia system, navigation, telephone, air conditioning |
| Face recognition | YES |
| Internet of Vehicles | YES |
| OTA upgrade | YES |
| Multimedia/charging interface | USB |
| Number of USB/Type-c ports | 2 in front |
| Number of speakers (pcs) | 4 |
| Lighting configuration | |
| Low beam light source | Halogen |
| High beam light source | Halogen |
| LED daytime running lights | YES |
| Automatic lamp head | YES |
| Headlight height adjustable | YES |
| Headlights turn off | YES |
| Glass/Rearview mirror | |
| Front power windows | YES |
| Rear power windows | YES |
| Window one-button lift function | Full car |
| Window anti-pinch function | YES |
| Post audition feature | Electric adjustment,rearview mirror heating |
| Inside rearview mirror function | Manual anti-dazzle |
| Interior vanity mirror | Main driver Co-pilot |
| Air conditioner/refrigerator | |
| Air conditioner temperature control method | Manual air conditioner |
| Smart hardware | |
| Number of cameras 11 | 3 |
| The number of ultrasonic radars is 12 | 11 |
| The number of millimeter wave radars is 5 | 1 |
