Product Information
AION S has a body length of 4768 mm x 1880 mm x 1530 mm, with a wheelbase of 2,750 mm. Its overall appearance is a bit like water droplets, the front face of cloud arrow is very handsome, suspension roof is also unconventional, particularly fashionable, especially the white body is particularly elegant. Moreover, Ian S vehicle quality sense is also very good, there is a so-called advanced sense, the steering wheel and the touch of the keys are very good. 12.3-inch instrument panel 12.3-inch central control large screen is very scientific and technological sense, work materials are very solid, almost all the touch is soft material, very high-end atmosphere show grade.
Panoramic skylight is not only a panoramic skylight with a wide view and can be opened, but also a hidden 'hidden technique'. It adopts the world's first solar energy self-circulation system, which can absorb solar energy in summer when the sun is too hot to automatically power the interior ventilation system, drive the air conditioning, keep the interior temperature at a comfortable temperature of about 10°C, so that you never have to worry about the car will become a 'big oven' in the hot summer. Can be said to be a practical and B - lattice black technology.
AION S has a maximum power of 100 kW, peak torque of 225N m, matching capacity of 58.8 KWH battery pack, comprehensive range of 460 km, 100 km acceleration of 7.9 seconds.
Product Specifications
| Brand | AION |
| Model | S |
| Version | 2022 XUAN 530 |
| Car model | Compact Car |
| Type of Energy | Pure electric |
| NEDC pure electric cruising range (KM) | 410 |
| Maximum power (KW) | 100 |
| Maximum torque [Nm] | 225 |
| Motor horsepower [Ps] | 136 |
| Length*width*height (mm) | 4768*1880*1530 |
| Body structure | 4-door 5-seat Sedan |
| Car body | |
| Longth(mm) | 4786 |
| Width(mm) | 1880 |
| Higth(mm) | 1530 |
| Wheel base(mm) | 2750 |
| Minimum ground clearance (mm) | 125 |
| Body structure | Sedan |
| Number of doors | 4 |
| Number of seats | 5 |
| Trunk volume (L) | 453 |
| Electric motor | |
| Motor type | Permanent magnet synchronization |
| Total motor power (kw) | 100 |
| Total motor torque [Nm] | 225 |
| Front motor maximum power (kW) | 100 |
| Front motor maximum torque (Nm) | 225 |
| Number of drive motors | Single motor |
| Motor placement | Prepended |
| Battery Type | Lithium iron phosphate battery |
| NEDC pure electric cruising range (KM) | 410 |
| Gearbox | |
| Number of gears | 1 |
| Transmission type | Fixed gear ratio gearbox |
| Short name | Electric vehicle single speed gearbox |
| Chassis Steer | |
| Form of drive | FF |
| Type of front suspension | McPherson independent suspension |
| Type of rear suspension | Torsion Beam Dependent Suspension |
| Boost type | Electric assist |
| Car body structure | Load bearing |
| Wheel braking | |
| Type of front brake | Ventilated Disc |
| Type of rear brake | Disc |
| Type of parking brake | Electric brake |
| Front Tire Specifications | 215/55 R17 |
| Rear tire specifications | 215/55 R17 |
| Cab Safety Information | |
| Primary driver airbag | YES |
| Co-pilot airbag | YES |
| Tire pressure monitoring function | Tire pressure display |
| Seat belt not fastened reminder | Front row |
| ISOFIX Child seat connector | YES |
| ABS anti-lock | YES |
| Brake force distribution (EBD/CBC, etc.) | YES |
| Brake Assist (EBA/BAS/BA, etc.) | YES |
| Traction Control (ASR/TCS/TRC, etc.) | YES |
| Body Stability Control (ESC/ESP/DSC, etc.) | YES |
| Assist/Control configuration | |
| Front parking radar | ~ |
| Rear parking radar | YES |
| Driving assistance video | Reverse image |
| Cruise system | Cruise control |
| Driving mode switching | Sport/Economy/Standard Comfort |
| Automatic parking | YES |
| Hill assist | YES |
| External / Anti-Theft Configuration | |
| Rim material | Steel |
| Interior central lock | YES |
| Key type | Remote control key |
| Keyless start system | YES |
| Battery preheating | YES |
| Internal configuration | |
| Steering wheel material | Plastic |
| Steering wheel position adjustment | Manual up and down |
| Multifunction steering wheel | YES |
| Trip computer display screen | Color |
| LCD meter size (inch) | 3.5 |
| Seat configuration | |
| Seat materials | Imitation leather |
| Driver's seat adjustment | Front and rear adjustment, backrest adjustment,height adjustment (2-way) |
| Co-pilot seat adjustment | Front and rear adjustment, backrest adjustment |
| Rear seats folded down | Proportion down |
| Front/rear center armrest | Front |
| Multimedia configuration | |
| Central control color screen | Touch LCD |
| Central control screen size (inch) | 12.3 |
| Satellite navigation system | YES |
| Navigation traffic information display | YES |
| Roadside assistance call | YES |
| Bluetooth/Car Phone | YES |
| Mobile phone interconnection/mapping | Support CarLife |
| Voice recognition control system | Multimedia system, navigation, telephone, air conditioning |
| Internet of Vehicles | YES |
| OTA upgrade | YES |
| Multimedia/charging interface | USB |
| Number of USB/Type-c ports | 2 in front/2 in rear |
| Number of speakers (pcs) | 2 |
| Lighting configuration | |
| Low beam light source | Halogen |
| High beam light source | Halogen |
| Headlight height adjustable | YES |
| Headlights turn off | YES |
| Glass/Rearview mirror | |
| Front power windows | YES |
| Rear power windows | YES |
| Window one-button lift function | Driver's seat |
| Window anti-pinch function | YES |
| Post audition feature | Electric adjustment |
| Inside rearview mirror function | Manual anti-dazzle |
| Air conditioner/refrigerator | |
| Air conditioner temperature control method | Automatic air conditioner |
| Rear air outlet | YES |
| Temperature zone control | YES |
